| Technical Data Sheet of High-efficiency Vertical Mill | |||||
| Model | Diameter(mm) | Height (mm) | Effective Volume (m³) | Motor Power (kW) | Rotational Speed (r/min) |
| VM800 | 800/1000 | 990/640 | 0.68 | 22 | 254 |
| VM1000 | 1000/1270 | 990/640 | 1 | 37 | 205 |
| VM1200 | 1200/1520 | 1200/640 | 2 | 55 | 172 |
Product Features
– This vertical mill features a wellreasoned structural design for easy onsite installation and convenient maintenance.
– Key wettedflow components including impeller, base guard plate and bushing are made of wearresistant rubber, delivering excellent antiabrasion and antiimpact performance. It greatly mitigates wear caused by material scouring, extends service life of wearing parts and reduces sparepart replacement frequency.
– Optimized flowpassage and transmission structures bring low energy consumption and low operating cost. The mill runs smoothly with minor vibration, ensuring high reliability for continuous operation in mineral processing plants.
Selection Guidelines
When placing an order, specify material type, Mohs hardness, maximum feed size, required hourly throughput and target finished particle size to confirm the model specification.
