| Technical Data Sheet of GBJ Efficient Agitation Tank | ||||||
| Model | Effective Volume(m³) | Impeller Rotational Speed(r/min) | Impeller Diameter(mm) | Motor Model | Motor Power(kW) | Weight(kg) |
| GBJ – 1000×1000 | 0.58 | 530 | 240 | Y112M – 6 | 2.2 | 548 |
| GBJ – 1250×1250 | 1.15 | 350 | 240 | Y100L – 4 | 3 | 108 |
| GBJ – 1500×1500 | 2.2 | 320 | 420 | Y132M₂ – 6 | 5.5 | 2207 |
| GBJ – 2000×2000 | 4.4 | 240 | 560 | Y160M – 6 | 7.5 | 3110 |
| GBJ – 2500×2500 | 9.2 | 232 | 560 | Y180L – 6 | 15 | 3939 |
| GBJ – 3000×3000 | 19.1 | 211 | 700 | Y225S – 8 | 18.5 | 4613 |
| GBJ – 4000×4000 | 45 | 153 | 1000 | Y250M – 8 | 30 | 9560 |
Product Features
-The diameter of the impeller is increased, which enhances the mixing capacity of ore pulp and chemicals.
-The linear speed of the impeller is increased, which improves the mixing capacity of ore pulp and chemicals.
-The impeller is designed as an umbrella-shaped impeller, further strengthening the mixing capacity of ore pulp and chemicals.
-The enhanced mixing capacity also boosts the circulation capacity of ore pulp and chemicals.
-There is a fluid guide in the tank, and the impeller is located inside the fluid guide. With the improved mixing capacity, the ore pulp generates greater negative pressure during operation. The fluid guide confines this negative pressure within a limited space, thereby accelerating the suction capacity for ore pulp and chemicals and further enhancing their circulation capacity.
-The umbrella-shaped impeller generates a downward pressure during operation, which further increases the suction capacity of ore pulp and strengthens the circulation capacity of ore pulp and chemicals.
-The lower part of the guide body is equipped with a jet device, where slurry and reagents enter, further enhancing the circulation capacity.
The thorough mixing and dispersion of slurry and reagents ensure complete reagentization of the mineral surfaces, which is favorable for flotation. Only when the mineral surfaces are 100% reagentized can a high flotation recovery rate be fully guaranteed.
Selection Guidelines
When placing an order, it is necessary to specify the model and quantity.
